Universal Air Portable™ Basketball Floor System
 |
FAST AND EASY INSTALLATION SET-UP & REMOVAL
First panels are easily assembled over concrete, synthetic, or appropriately installed ice arena.
CONSTRUCTION
The portable floor panels use Northern Hard Maple, Beech or Ash, factory assembled over a structural subfloor system, lighter weight, easy to handle and to load in containers.
The sub-floor fastening/locking "concealed" (hidden) system ensures control of expansion due to normal changes in humidity, for a tight fitting and level-playing surface.
The "concealed" locking system leaves the surface free of nails and locking hardware for greater safety. Players perform better with less fatigue and less chance of leg and ankle injuries.
The floor and sealer finish are an Oil Modified Urethane Finish, for appropriate slide resistance and enviormentally safe.
Court marking paint for standard game lines according to international federations (optional perimeter paint, logos, lettering available).
BENEFITS
Allows the facility/coliseum to schedule multi-purpose events within the same day. Standard and Special sizes, suitable for Basketball, Volleyball, Handball, Netball, Badminton, Futsal and other multi-purpose sport activities.
UNIVERSAL AIR RESILIENT
 The Portable is also available with attached rubber pads to provide more resilience and comfort to the players. Resilient Sub-Floor construction, the cushion pads provides added shock absorption and more comfort for players. Resilient Pads enhance the shock absorption, Ball Bounce, Deflection and performance.
|
DIN TESTING STANDARDS
|
 |
|
Shock Absorption (Safety)
Amount of load absorbed by the floor
DIN Standard: Wood: Minimum 53%
|
 |
|
Vertical Deflection (Safety & Performance)
Vertical movement of the floor during impact at the
point of touch down and within 50cm of that point.
DIN Standard: Wood: Minimum 2.3mm
|
 |
|
Ball Bounce (Performance)
Ball return off the floor as compared to concrete
DIN Standard: Wood: Minimum 90%
|
 |
|
Sliding Characteristics/Properties (Safety)
Surface slide characteristics
DIN Standard: Wood: Range: Min 0.4 - Max 0.6
|
 |
|
Rolling Load (Durability)
Resource for technical information and guidance
for maple hardwood floors. Establishes rules of
species, quality and grading.
|
CERTIFICATIONS
|
 |
|
international Basketball Federation (FIBA)
International governing organization for
international basketball competitions for all 3 levels
of competition (I, II, III). Establishes standards
and homologation of facilities.
|
 |
|
DIN Performance Testing
Floor Methods and Technology
DIN Standard V 18032-2 (MPA-OTTO-GRAF-
INSTUT, UNVERSITAT STUTTGARD, GERMANY)
Standards, of Safety, Performance & Durability
|
 |
|
Maple Flooring Manufacturing Assocation (MFMA)
Resource for technical information and guidance for
maple hardwood floors. Establishes rules of species,
quality and grading.
|
|
  |
|
